| 브랜드 이름: | AE |
| 모델 번호: | AE85 |
| 모크: | 10 평방 미터 |
| 가격: | USD 90-110 Per Square Meter |
| 지불 조건: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| 공급 능력: | 한 달에 1000 평방 미터 |
AE Partition: The Art of Acoustic Sophistication
We craft more than just partitions; we create unparalleled acoustic environments. AE Partition is the premier choice for architects, designers, and clients who demand uncompromising quality and aesthetic excellence. Our bespoke solutions, including the elegantly engineered office divider partition wall, grace sophisticated commercial, hospitality, and residential spaces across the globe (UK, Germany, US). Partner with us to transform your vision into a masterpiece of function and design.
SPECIFICATION:
| GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSONAL SPACE SOLUTIONS | ||||||
| Dimensions in mm* | Design | |||||
| Series | Element thickness | Element width* (min./max.) | Clear height* (min./max.) | Framed construction | Panel fixing | Element interconnection/design of the vertical profiles |
| AE65 | 68 | 600/1,250 | 2,000/4,500 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
| AE85 | 89 | 600/1,250 | 2,000/5,500 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
| AE100 | 105 | 600/1,250 | 2,000/18,000 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
| Technology: Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB):52/56 Positive and frictional locking of the vertical element connections: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m * Larger widths possible on application. Provisional details regarding the element heights/element widths indicated can only be confirmed following consultation with the Design Department. ** Depending on the sound insulation/weight |
||||||
