Commercial Movable Partition Wall with 105CM Thickness and 42-56dB STC Rating for Meeting Rooms

브랜드 이름:	AE
모델 번호:	AE100
모크:	10 평방 미터
가격:	USD 90-135 Per Square Meter
지불 조건:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
공급 능력:	한 달에 1000 평방 미터

자세한 정보

제품 설명

자세한 정보

원래 장소:

광동, 중국

인증:

ISO9001 SGS

제품 이름:

상업적인 접힌 파티션 월

애플리케이션:

댄스룸 파티션

규정 준수:

방, 학교를 만나기

두께:

105cm

STC 등급:

42-56데시벨

치수:

맞춤형(높이: 최대 18M, 패널당 너비: 최대 1.2M)

포장 세부 사항:

폼 층 및 합판 케이스 또는 스틸 팔레트가있는 하드 골판지

강조하다:

105CM Thickness Movable Partition Wall

42-56dB STC Rating Movable Partition Wall

304 Stainless Steel Movable Partition Wall

제품 설명

Mobile Folding Partition Walls - Commercial Melamine Meeting Room Sliding Partitions

Our mobile folding partition walls provide an efficient and versatile solution for space management in commercial environments. The top-hung design eliminates the need for floor tracks, simplifying both installation and operation.

Premium Construction & Features

Robust high-density aluminum frame construction
Specialized rubber seals and advanced soundproofing materials
Polished surface for superior acoustic performance in conference environments
Rubber seals along panel edges prevent sound leakage
Aluminum track system with multi-directional wheels for effortless movement

High-Quality Service Commitment

SGS and ILAC-MRA certified products for reliable performance
Incorporates leading German partition technology for professional space solutions
Engineered for long-term performance stability and extended lifespan
Quick follow-up and transparent quoting services
On-site inspection services to ensure quality implementation
Punctual delivery to maintain project schedules

Advanced Roller System

Dupont POM rollers for optimal performance
304 stainless steel construction with heavy-duty capabilities
Precision CNC machining with integrated safety features
Patented wheel design ensures smooth operation

Panel Specifications

100mm thickness for enhanced stability and sound insulation
Multiple acoustical and decorative finish options available
6061-T6 profile with Q235 steel frame for exceptional durability
Top and bottom jack lifting mechanisms with 800N sealing power
Magnetic seal with concave/convex profiles (40N/m attraction)

Technical Specifications

Series	Element Thickness (mm)	Element Width (mm)*	Clear Height (mm)*	Construction	Panel Fixing	Vertical Profile Design
AE65	68	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE85	89	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE100	105	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips

* Larger widths available upon request. Provisional dimensions subject to confirmation by Design Department.
Weighted sound reduction value (Rw): 52-56 dB (GB/T19889.3-2005)
Positive and frictional locking with convex-concave profile form (40 N/m magnetic attraction)
