| 브랜드 이름: | AE |
| 모델 번호: | AE85 |
| 모크: | 10 평방 미터 |
| 가격: | USD 80-100 Per Square Meter |
| 지불 조건: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| 공급 능력: | 한 달에 1000 평방 미터 |
| Series | Element thickness (mm) | Element width* (min/max) | Clear height* (min/max) | Construction | Panel fixing | Element interconnection |
|---|---|---|---|---|---|---|
| AE65 | 68 | 600/1,250 | 2,000/4,500 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
| AE85 | 89 | 600/1,250 | 2,000/5,500 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
| AE100 | 105 | 600/1,250 | 2,000/18,000 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
Technology: Weighted sound reduction value (Rw) determined per GB/T19889.3-2005: 52/56 dB
Locking System: Positive and frictional locking with convex-concave profile form, magnetic strip attraction force of 40 N/m
* Larger widths available upon request. Final dimensions subject to Design Department confirmation.
