| 브랜드 이름: | AE |
| 모델 번호: | AE65 |
| 모크: | 10 평방 미터 |
| 가격: | USD 70-98Per Square Meter |
| 지불 조건: | L/C,D/A,D/P,T/T,웨스턴 유니온,MoneyGram |
| 공급 능력: | 한 달에 1000 평방 미터 |
Office Acoustic Operable Partition Wall System with wooden finish
Our cost-effective soundproof movable partition wall systems feature built-in passageway doors, providing both privacy and accessibility. These partitions create quiet, adaptable spaces while maintaining budget efficiency.
| Series | Element Thickness (mm) | Element Width (min/max mm) | Clear Height (min/max mm) | Construction | Panel Fixing | Element Interconnection |
|---|---|---|---|---|---|---|
| AE65 | 68 | 600/1,250 | 2,000/4,500 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
| AE85 | 89 | 600/1,250 | 2,000/5,500 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
| AE100 | 105 | 600/1,250 | 2,000/18,000 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
Technology: Weighted sound reduction value (Rw): 52/56 dB (determined per GB/T19889.3-2005)
Element Connections: Positive and frictional locking with convex-concave profile form, magnetic strip attraction force of 40 N/m
* Larger widths available upon request. Final dimensions subject to Design Department confirmation.
